本圖集適用于鋼筋混凝土方形、矩形蓄水池的設計選用與施工。蓄水池適用于貯盛符合《生活飲用水衛生標準》GB 5749-2006的生活飲用水或符合《城市污水再生利用 城市雜用水水質》GB/T 18920-2020的非飲用水（含消防水池）。抗震設防烈度不大于8度（含設計基本地震加速度值0.3g）。 主要內容：包括矩形鋼筋混凝土蓄水池工藝布置和墻體、頂板、底板等結構設計及水管吊架等附屬配件做法。其規格為容積50m3～2000m3，每個容積又分為正方形和長方形兩種平面尺寸；蓄水池池頂及池壁外均考慮覆土，池頂覆土厚度分為500mm、1000mm、1500mm(部分蓄水池)三種。 本圖集按現行結構設計規范及工程應用需求對原國標圖集《矩形鋼筋混凝土蓄水池》進行修編。池頂覆土厚度增加1500mm工況，提高混凝土強度等級，修改保護層厚度。由于新規范可靠度提高，按新規范重新計算配筋，調整板厚及最小配筋率等構造措施。
22S804······1
編制說明······10
50m3方形蓄水池總布置圖······13
50m3方形蓄水池頂、底板配筋圖（池頂覆土500mm）······14
50m3方形蓄水池池壁平面及剖面配筋圖（池頂覆土500mm）······15
50m3方形蓄水池頂、底板配筋圖（池頂覆土1000mm）······16
50m3方形蓄水池池壁平面及剖面配筋圖（池頂覆土1000mm）······17
50m3矩形蓄水池總布置圖······18
50m3矩形蓄水池頂、底板配筋圖（池頂覆土500mm）······19
50m3矩形蓄水池池壁平面及剖面配筋圖（池頂覆土500mm）······20
50m3矩形蓄水池頂、底板配筋圖（池頂覆土1000mm）······21
50m3矩形蓄水池池壁平面及剖面配筋圖（池頂覆土1000mm）······22
100m3方形蓄水池總布置圖······23
100m3方形蓄水池頂、底板配筋圖（池頂覆土500mm）······24
100m3方形蓄水池池壁平面及剖面配筋圖（池頂覆土500mm）······25
100m3方形蓄水池頂、底板配筋圖（池頂覆土1000mm）······26
100m3方形蓄水池池壁平面及剖面配筋圖（池頂覆土1000mm）······27
100m3矩形蓄水池總布置圖······28
100m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······29
100m3矩形蓄水池底板配筋圖（池頂覆土500mm）······30
100m3矩形蓄水池池壁平面及剖面配筋圖（池頂覆土500mm）······31
100m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······32
100m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······33
100m3矩形蓄水池池壁平面及剖面配筋圖（池頂覆土1000mm）······34
150m3方形蓄水池總布置圖······35
150m3方形蓄水池頂板配筋圖（池頂覆土500mm）······36
150m3方形蓄水池底板配筋圖（池頂覆土500mm）······37
150m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······38
150m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······39
150m3方形蓄水池底板配筋圖（池頂覆土1000mm）······40
150m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······41
150m3矩形蓄水池總布置圖······42
150m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······43
150m3矩形蓄水池底板配筋圖（池頂覆土500mm）······44
150m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······45
150m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······46
150m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······47
150m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······48
200m3方形蓄水池總布置圖······49
200m3方形蓄水池頂板配筋圖（池頂覆土500mm）······50
200m3方形蓄水池底板配筋圖（池頂覆土500mm）······51
200m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······52
200m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······53
200m3方形蓄水池底板配筋圖（池頂覆土1000mm）······54
200m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······55
200m3矩形蓄水池總布置圖······56
200m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······57
200m3矩形蓄水池底板配筋圖（池頂覆土500mm）······58
200m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······59
200m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······60
200m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······61
200m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······62
300m3方形蓄水池總布置圖······63
300m3方形蓄水池頂板配筋圖（池頂覆土500mm）······64
300m3方形蓄水池底板配筋圖（池頂覆土500mm）······65
300m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······66
300m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······67
300m3方形蓄水池底板配筋圖（池頂覆土1000mm）······68
300m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······69
300m3方形蓄水池頂板配筋圖（池頂覆土1500mm）······70
300m3方形蓄水池底板配筋圖（池頂覆土1500mm）······71
300m3方形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······72
300m3矩形蓄水池總布置圖······73
300m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······74
300m3矩形蓄水池底板配筋圖（池頂覆土500mm）······75
300m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······76
300m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······77
300m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······78
300m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······79
300m3矩形蓄水池頂板配筋圖（池頂覆土1500mm）······80
300m3矩形蓄水池底板配筋圖（池頂覆土1500mm）······81
300m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······82
400m3方形蓄水池總布置圖······83
400m3方形蓄水池頂板配筋圖（池頂覆土500mm）······84
400m3方形蓄水池底板配筋圖（池頂覆土500mm）······85
400m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······86
400m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······87
400m3方形蓄水池底板配筋圖（池頂覆土1000mm）······88
400m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······89
400m3方形蓄水池頂板配筋圖（池頂覆土1500mm）······90
400m3方形蓄水池底板配筋圖（池頂覆土1500mm）······91
400m3方形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······92
400m3矩形蓄水池總布置圖······93
400m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······94
400m3矩形蓄水池底板配筋圖（池頂覆土500mm）······95
400m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······96
400m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······97
400m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······98
400m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······99
400m3矩形蓄水池頂板配筋圖（池頂覆土1500mm）······100
400m3矩形蓄水池底板配筋圖（池頂覆土1500mm）······101
400m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······102
500m3方形蓄水池總布置圖······103
500m3方形蓄水池頂板配筋圖（池頂覆土500mm）······104
500m3方形蓄水池底板配筋圖（池頂覆土500mm）······105
500m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······106
500m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······107
500m3方形蓄水池底板配筋圖（池頂覆土1000mm）······108
500m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······109
500m3方形蓄水池頂板配筋圖（池頂覆土1500mm）······110
500m3方形蓄水池底板配筋圖（池頂覆土1500mm）······111
500m3方形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······112
500m3矩形蓄水池總布置圖······113
500m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······114
500m3矩形蓄水池底板配筋圖（池頂覆土500mm）······115
500m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······116
500m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······117
500m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······118
500m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······119
500m3矩形蓄水池頂板配筋圖（池頂覆土1500mm）······120
500m3矩形蓄水池底板配筋圖（池頂覆土1500mm）······121
500m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1500mm）······122
600m3方形蓄水池總布置圖······123
600m3方形蓄水池頂板配筋圖（池頂覆土500mm）······124
600m3方形蓄水池底板配筋圖（池頂覆土500mm）······125
600m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······126
600m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······127
600m3方形蓄水池底板配筋圖（池頂覆土1000mm）······128
600m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······129
600m3矩形蓄水池總布置圖······130
600m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······131
600m3矩形蓄水池底板配筋圖（池頂覆土500mm）······132
600m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······133
600m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······134
600m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······135
600m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······136
800m3方形蓄水池總布置圖······137
800m3方形蓄水池頂板配筋圖（池頂覆土500mm）······138
800m3方形蓄水池底板配筋圖（池頂覆土500mm）······139
800m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······140
800m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······141
800m3方形蓄水池底板配筋圖（池頂覆土1000mm）······142
800m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······143
800m3矩形蓄水池總布置圖······144
800m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······145
800m3矩形蓄水池底板配筋圖（池頂覆土500mm）······146
800m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······147
800m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······148
800m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······149
800m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······150
1000m3方形蓄水池總布置圖······151
1000m3方形蓄水池頂板配筋圖（池頂覆土500mm）······152
1000m3方形蓄水池底板配筋圖（池頂覆土500mm）······153
1000m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······154
1000m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······155
1000m3方形蓄水池底板配筋圖（池頂覆土1000mm）······156
1000m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······157
1000m3矩形蓄水池總布置圖······158
1000m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······159
1000m3矩形蓄水池底板配筋圖（池頂覆土500mm）······160
1000m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······161
1000m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······162
1000m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······163
1000m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······164
1500m3方形蓄水池總布置圖······165
1500m3方形蓄水池頂板配筋圖（池頂覆土500mm）······166
1500m3方形蓄水池底板配筋圖（池頂覆土500mm）······167
1500m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······168
1500m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······169
1500m3方形蓄水池底板配筋圖（池頂覆土1000mm）······170
1500m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······171
1500m3矩形蓄水池總布置圖······172
1500m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······173
1500m3矩形蓄水池底板配筋圖（池頂覆土500mm）······174
1500m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······175
1500m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······176
1500m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······177
1500m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······178
2000m3方形蓄水池總布置圖······179
2000m3方形蓄水池頂板配筋圖（池頂覆土500mm）······180
2000m3方形蓄水池底板配筋圖（池頂覆土500mm）······181
2000m3方形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······182
2000m3方形蓄水池頂板配筋圖（池頂覆土1000mm）······183
2000m3方形蓄水池底板配筋圖（池頂覆土1000mm）······184
2000m3方形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······185
2000m3矩形蓄水池總布置圖······186
2000m3矩形蓄水池頂板配筋圖（池頂覆土500mm）······187
2000m3矩形蓄水池底板配筋圖（池頂覆土500mm）······188
2000m3矩形蓄水池池壁及支柱配筋圖（池頂覆土500mm）······189
2000m3矩形蓄水池頂板配筋圖（池頂覆土1000mm）······190
2000m3矩形蓄水池底板配筋圖（池頂覆土1000mm）······191
2000m3矩形蓄水池池壁及支柱配筋圖（池頂覆土1000mm）······192
水管吊架詳圖······193
檢修孔及木蓋板詳圖······194
保溫檢修孔及不銹鋼蓋板詳圖······195
A、B、C型集水坑詳圖······196
D、E、F型集水坑詳圖······197
通風孔及A型通風管詳圖······198
B型通風管詳圖······199
鋼梯大樣圖······200
A型蓄水池溢水井······201
B型蓄水池溢水井······202
蓄水池溢水井(A型井埋深2m、3m）······203
蓄水池溢水井(B型井埋深2m、3m）······204
蓄水池溢水井鋼筋表······205
套管洞加固詳圖······206
液位儀預埋管件詳圖······207
液位儀安裝詳圖······208
